?TypeA (2.5mm) ?TypeB (1.25mm, flat)

Feature:

• Designed so that all operators can consistently achieve high quality cleaning without alcohol or other solvents.

• Palm-sized and lightweight. Easy and safe to use whether in the engineering lab, on the production line, or in the field.

• Cleaning tape is replaceable and cost effective.

• One cleaning tape can be used for over 400 wipes.

• Has excellent anti-static properties to avoid reattachment of dust to the ferrule after cleaning.

Easy to replace tape cartridge

the tape can be replaced very easily by a "drop-in" cartridge.

One push operation

Available for both left hand and right handed operators.

Anti-static propeties

Has excellent anti-static properties for static sensitive applications and can avoid reattchment of dust to the ferrule after cleaning.

Specifications

FerruleTypePart No.

Φ2.5mm	Φ1.25mm
Type A	Type B
14110501	14110601
Shape of rubber pad
Cleans per cartridge	More than 400 times	More than 400 times
Connectots cleande	SC, SC2, FC, ST, DIN, D4	MU, LC, MT, MPO, MT-RJ without pins, Biconic
Dimension W × H × D mm	125 × 85 × 35
Weight (g)	150	150
Packaging	1	1
Remarks	-	-

ConsumablesPart No. of cosumable

Replacement cartridge blue (6 pcs/set)	Replacement cartridge white (6 pcs/set)
14110700	14110710

Notice1: Please do not use this product for other purposes than cleaning ferrule end-faces.
Notice2: the cleaning perforrmance may change depending upon the environment and contamination types.
