1. Product Specification

1).Size: 6mm-36mm
2).Heat treatment: Quenched, tempered
3).Finish: Hot dip galvanized.
4).Material: Alloy steel

2. Technical Parameter

Item No.	SWL kg	A	B	C	D	E	F	L	Weight each kg kg
CG-06 CG-08 CG-10 CG-12 CG-16 CG-20 CG-22 CG-24	100 200 300 500 1000 1500 2200 3000	6X100mm 8X125mm 10X150mm 12X200mm 16X250mm 20X300mm 22X330mm 24X350mm	145 185 210 275 345 435 480 555	215 280 325 430 540 670 740 830	12 14 16 19 23 28 34 36	10 12 14 18 24 26 32 36	6 8 9 11 14 18 20 21	100 125 150 200 250 300 330 350	0.06 0.125 0.250 0.480 0.980 1.650 2.350 2.750
