| Processing Type: | Plastic Thermoforming Machine |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | 1year |
| Weight: | 6T |
| Dimension(L*W*H): | 4.5m*1.8m*2.4m |
| Power(W): | 100KW |
| Voltage: | 380V |
| Model Number: | yx750 |
| Brand Name: | YONGXU |
| Place of Origin: | China (Mainland) |
| Product Type: | Plastic Cup |
| Condition: | New |
| forming area: | 750*350mm |
| deepth: | 130mm |
| speed: | 10-30times/min |
Quick Details
Specifications
Material |
PP/PE/PS (Hard Sheet) |
Sheet THickness |
0.3-2.0mm |
SheetWidth |
500-720mm |
MaxInstall Area |
750×350mm |
Max Forming Area |
720*300mm |
up Heater Power |
10Rows*9Zones*850w |
Down Heater Power |
9Rows*9Zones*850w |
Max Shaping Depth |
190mm |
MaxFOrmingDepth |
130mm |
Productivity |
10-30Strokes/min |
HeatingRatedPower |
≈50kw |
Total Power |
100Kw |
MainMotor Power |
11kw |
PowerSupply |
380V/50Hz(Three phase four wire) |
Voltage |
0.6-0.8Mpa |
Air VOlumeREquired |
2500～3500L/min |
Water VOlumeREquired |
40～45L/min |
MachineWeight |
about6T |
Overall Dimension |
4.5m*1.8m*2.4m |
