QC11Y-8*2500  HYDRAULIC METAL SHEARER



 Machine  Features

1.this machine adopts the steel plate welded structure, the fuselage uses the Finite element Analysis and design, Vibration stress relief, the fuselage Is stable and reliable.

2.by using the three point Support rolling Wheel, the elimination of Supporting gap, Improving shearing accuracy.

    3.Carriage of shearing Angle can be adjusted

4.Shearing stroke Adjusted, Improved work efficiency, Can realize sectional Shear.

5.after the block Design manual Lifting Function, easy long plate Shearing.

6.the inner side of the wall Is provided with a Manual oil pump ,convenient operation, Ensure the lubrication.

7.Cartridge type hydraulic System Oil temperature, slow Ascending, Enhance there Liability and safety of the Machine tool Operation.





Technical  parameters

Specification	Unit	QC11Y-8×2500
Max. cutting thickness	mm	8
Max. cutting width	mm	2500
Can be cut strength of plate	Mpa	450
Shearing angle	°	0.5~2°
Stroke time	Times/min	14~30
Backgauge range	mm	20-600
Motor power	kw	11
Machine size	mm	3150x1580x2050
