CE Certificated ZTS-320R Reflectorless Total Station Surveying Instruments


Technical Parameter of the Total Station:

Angle Measurement

Measurement Method: Absolute Encoding

Minimum Readout: 1″/5″/10″(0.3mgon/1.5mgon/3mgon) Adjustable

Accuracy1: 2"



Distance Measurement (ZTS-320 with Reflector)

Single Prism: 3000m (9,842ft.) under good condition3

Three Prisms: 6000m (19,685ft.) under good condition3

Reflective Sheet: 800m (2,624 ft.)

Accuracy: 2 mm+2ppm

Measuring Time (Fine/Quick/Tracking): 1.5s/1s/ 0.5s



Distance Measurement(ZTS-320R Reflectorless)

Reflectorless2 Range: 350m(1,148 ft.)

Single Prism: >7500m(24,606ft.)

Accuracy: 3mm+2ppm

Measuring Time: 1.5s



Telescope

Magnification: 30X

Field of View: 1°30′ (2.7m at 100m)

Minimum Focusing Distance:1.5m

Reticle: Illuminated



Compensator

System: Single-axis liquid tilt sensor/Dual-axis (optional)

Working Range: ±3′

Setting Accuracy: 1″



Communication

Bluetooth

Interface:Standard RS232,SD card4,USB pen drive,mini-B

Internal Data Memory:Approx.20,000 Points

Data Format:ASCII



Operation

Operation system: Real-time Operating System

Display:High resolution backlight black and white display with contrast adjustment/ Graphics: 192 x 96 pixels

Character:6 lines x 25 characters

Keyboard:2 sides Alphanumeric backlit crystal keyboard



Laser Plummet

Type:Laser point, 4 brightness levels adjustment / Optical plummet (optional)

Centering Accuracy:1 mm at 1.5m instrument height



Power Supply

Battery Type:Rechargeable Li-ion battery

Voltage/Capacity:ZBA-400: 7.4V (DC) / 3000mAh

Operating Time with ZBA-400:Optimal 16 hours5 (Continuous angle measurement every 30 seconds)/10 hours (typical)

Measuring Times:Approx. 12000 times



Weight

Weight (Incl. Battery & Tribrach): Approx. 5.5kg (12.1lb.)



Environmental

Operating Temperature: -20℃ ~+50℃( -4℉ to + 122℉)

Storage Temperature: -40℃ ~+70℃(-40℉to + 158℉)

Dust &Water Proof (IEC60529 Standard)/Humidity: IP65, 95%, non-condensing)
