| After-sales Service Provided: | Overseas service center available |
|---|---|
| Warranty: | 1 |
| Certification: | 1 |
| Weight: | 1 |
| Dimension(L*W*H): | 1 |
| Model Number: | 1 |
| Brand Name: | 1 |
| Place of Origin: | Alderney |
| Capacity(t/h): | 1 |
| Power(W): | 1 |
| Motor Type: | AC Motor |
| Type: | Ball Mill |
| Condition: | New |
Quick Details
Specifications
Specifications
Warranty:one year
Fuel:anthracite,coke
Calorific Value:5000-6500kcal/Kg
Activity degree:≥280ml,up to 350ml
Packaging & Delivery
Packaging Details:Standard Export Package
Delivery Detail:30 days against down payment
Product Description
Vertical Lime Kiln is building material equipment, is the main equipment for sintering cement clinker in cement production plant, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.
Vertical Lime Kiln is used in the most important equipment in lime production line.
Detailed Parameters
Kiln total height:32—52.8M (according to the output)
Kiln effective height:16.5—34.5M (according to the output)
Kiln outer diameter:3.6—7.5M (according to the output)
Kiln inner diameter:2.4—5.3M (according to the output)
Structure:Steel structure outside and firebrick build inside
Area:2000—4000m2
Output capacity:50—400tons
Kiln volume:75-750m3
Limestone particle size:40—80mm
Limestone calcine temperature:900—1200°C
Lime discharging temperature:40—80°C
Lime calcine cycle:Circulating
Availability of lime:280—320ml
Calcium oxide contents:80—95%
Defective lime rate:<10%
Fuel:anthracite,coke
Coal consumption:130kg standard coal per ton lime
Control system:PLC control
Monitor system:24 hours monitor
Operators:Two kilns one group, each group three operators
High temperature pocket type dust removing rate:99%
Desulphurization rate:95%
Environmental standard:National secondary standard
Draft fan wind pressure/wind volume:300pa/3500m3/h
Forced fan wind pressure/wind volume:4000pa/30000m3/h
Wind blow type:Ring shaped machinery continuous fan
Lime discharging type:All sides discharge
Power:135—283.5Kw
Construction period:100—120 working days
Advantages
1. International High Quality Certification:
to open the globle market,we have passed the ISO 9001,ISO 50430,ISO14000,BV certification,quality guarantee.
2. Manufacture.
OEM service,QC system with more resonable price.
3. Experienced Techncians.
with over 20 years' practical experience,our engineers and workers can skillfully complete the process.
4.Competitive Price
Payment terms can be negotiated,more reasonable price under the same quality.
