| Type: | Other |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | ISO9001 |
| Dimension(L*W*H): | 1200*860*2000 |
| Weight: | 5000kg |
| Model Number: | GT4B27 |
| Brand Name: | Brilliant |
| Place of Origin: | China (Mainland) |
| Power: | see below |
| Voltage: | 220V/380V |
| Driven Type: | Electric |
| Automatic Grade: | Automatic |
| Packaging Material: | Paper,Wood |
| Packaging Type: | Case |
| Application: | Chemical,Machinery & Hardware |
| Condition: | New |
| Output capacity (cans/min): | 20-25 |
| Diagonal line(mm): | 160-190 |
| Can height (mm): | 115-390 |
| Air pressure (mpa): | 0.3-0.5 |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
the can seamer has 6 seaming rollers,this combination include two seamers,one overturning device and conveyors,it could be used by all type of tin can factory,such as food,food oil,paint and lubricant oil factory.this machine is mainly used for 3-4L rectangle cans(it could adjust as per client requirement),customer could buy any part of the combination as per need. Long life.Embracing device drived by servo motor and ball screw,so the precision is high and seaming quality is high.Ⅰ.Function
this machine is steady,simple and easy to operate.It controlled by PLC with low noise and Ⅱ.Major technical parameters Output capacity (cans/min)
20-25 Diagonal line(mm)
160-190 Can height (mm)
115-390 Thickness of tinplate(mm)
≤0.4 Air pressure (mpa)
0.3-0.5 Motor type
Y100L1-4 2.2 First conveyor(mm)
1500 Second conveyor(mm)
2000 Size (mm)
1200×860×2000 Weight (kg)
5000
3.Product production process:
4.Our service
