Rccb f362 f364 model 2 pole 4 pole F360 earth leakage circuit breaker

Application & Features

1.Elegant appearance, cover and handle in arc shape make comfortable operation.
  Contact position indicating window.
Case of overload to protected circuit,RCCB handle trips and stays at central position, which enables a
  quick solution to the faulty line.the handle cannot stay in such position when operated manually.
3.Provides protection against earth fault/leakage current and function of isolation.
4.High short-circuit current withstand capacity
5.Applicable to terminal and pin/fork type busbar connection

Technical Data

Model: Electro-magnetic type
Residual Current Characteristics: A, AC
Pole No.: 2, 4
Rated Making and Breaking Capacity: 630A
Rated Current (A): 16, 25, 32, 40, 50, 63A
Rated Voltage: 240/415V AC
Rated Frequency: 50/60 Hz
Rated Residual Operating Current IΔn (A): 0.01, 0.03, 0.1, 0.3, 0.5
Rated Residual Non-operating Current I Δno: 0.5I Δn
Rated Conditional Short-circuit Current Inc: 10kA
Rated Conditional Residual Short-circuit Current I Δc: 10kA
Tripping Duration: Instantaneous tripping ≤ 0.1s
Residual Tripping Current Range: 0.5 IΔn~10.5 IΔn
Terminal Connection Height: 19mm
Electro-mechanical Endurance: 4000 cycles
Connection Capacity: Rigid conductor 25mm2
Connection Terminal: Screw terminal


Type	Rated Current(A)	LeakAge Acting Current	Range of Break-off	Rated Voltage
SF362	16A,25A,32A,40A,63A	10mA,30mA,100mA,300mA	0.5~1.0	230V(220V)
SF364	25A,32A,40A,63A	30mA,100mA,300mA	0.5~1.0	230V/415V (220V/380V)
