General characteristics
Sensor		DS06	Color, Sony IMX 238 CMOS, 1.3MP  2.8mm  lens
		DS06M	Color, Sony IMX 225 CMOS, 1.3MP  2.8mm  lens
Resolution			1280*1024 (effective pixels)
			Black Light Compensation,3D noise reduction
Sensitivity			0.1 lux (day) / 0.01 (Night) 0 Lux (with incl. Backlight)
DWDR			Digital Wide Dynamic Range(DWDR)
Video
Compression Format			H.264 MP, Motion JPEG
Stream Video			Dual encoding: H.264 / MJPEG, H.264 / H.264, MJPEG / MJPEG
Resolution			960x576, 720x576 (Full D1), 704x576 (D1), 704x288 (2CIF),
			352x288 (CIF), 176x144 (QCIF)
Frame rate			Up to 25 / s for all resolutions (H.264)
Audio
Compression			G.711 (u-law, a-law), G.726
Additionally			Two-way audio channel
Network and interfaces
Network interface			10Base-T / 100Base-TX Ethernet port
Network Protocols			TCP, HTTP, FTP, SMTP, DNS, DHCP, PPPoE, POP3, RTP, RTSP, UDP, NTP, ARP
IR illumination
LEDs			IR LED Lattice-type (1 pc.), IR Cut Filter
Illumination Level			Automatically adjustable
Range			10 meters
Operation
PoE			PoE IEEE 802.3 AF
Operating temperature range			- 40 To + 50℃
Ingress Protection			IP55 , Metal coated with a corrosion-resistant polyester powder paint
Dimensions (WxHxD)			73*166*51 mm
Management			Professional Software Intercom (included)
			Field of View Adjustment: rotatable body
Components
Scope of delivery			Door station
			Outside panel
			Switching box
			CD (with software and documentation)
			Package
