Mutirip circular saw blade
1. the basic circular saw blade
Application: longitudinal cutting solid wood, thin sawline, and for plyboard cutting.
Feature: low sawline, sharp & durable.
| Diameter |
Kerf | Bore | Pitch | Sharp of teerh |
| 150 | 1.4-3.0 |
40/50 | 24T | ATB |
| 255 | 1.6-3.0 | 40/50 | 36T | ATB |
| 305 | 1.6-3.2 | 50/60/70 | 40T | ATB |
| 405 | 2.8-3.6 | 50/60/70 | 40T | ATB |
the range of diameter: 100-700mm
the range of kerf: 0.8-6.0mm
2. Multi-rip circular saw blade with rakers
Feature: material-saving, high efficiency, with smooth cutting surface, without burr.
Some dimensions of the multi-rip saw blades are shown below:
Other sizes can be customized. We can produce:
the range of diameter: 100-700mm
the range of kerf: 0.8-6.0mm
3. Multi-rip circular saw blade with the thicker steel body
Application: longitudinal & crossing cutting many kinds of precious woods.| Diameter | Kerf | Bore | Pitch | Teeth sharp |
| 180 | 1.4-3.0 | 40/50 | 24+3T | ATB |
| 255 | 1.6-3.0 | 40/50 | 36+4T | ATB |
| 355 | 2.2-3.4 | 50/60/70 | 40+4T | ATB |
| 405 | 2.8-3.6 | 50/60/70 | 40+4T | ATB |
the range of diameter: 100-700mm
the range of kerf: 0.8-6.0mm
Feature: low sawline, less cutting losses, deformation won't happen after long time using.
Some dimensions of the multi-rip saw blades are shown below:
Diameter |
Kerf |
Bore |
Pitch |
Teeth sharp |
160 |
1.0-1.6 |
40/50 |
24T |
ATB |
205 |
1.2-1.6 |
40/50 |
36T |
ATB |
230 |
1.3-1.8 |
50/60/70 |
40T |
ATB |
305 |
1.5-2.0 |
50/60/70 |
40T |
ATB |
Other sizes can be
Customized. We can produce:
the range of Diameter: 100-700mm
the range of kerf: 0.8-6.0mm
