| Efficiency: | IE 2 |
|---|---|
| Place of Origin: | China (Mainland) |
| Phase: | Three-phase |
| Output Power: | 0.74HP(0.55KW) ~ 60HP(45KW) |
| Frequency: | 50Hz(60Hz is available on request) |
| Type: | Asynchronous Motor |
Quick Details
Specifications
OPERATIING CONDITIONS and DATA
Application:
Mechanical equipment and transmission device for rapid stop and accurate positioning.
Ambient temperature: |
-15℃≤ θ ≤40 ℃ |
Altitude: |
Not exceeding 1000meters |
Rated voltage: |
380V ± 5% |
Rated frequency: |
50Hz ( 60Hz is available on request ) |
Frame size |
H80～225mm |
Output: |
0.74HP(0.55KW) ~ 60HP(45KW) |
Asynchronous speed |
3000r/min 50Hz; 1500r/min 50Hz; 1000r/min 50Hz; |
Connection: |
Y Star-connection |
Insulation class: |
Class F |
Protection class: |
IP55 |
Application:
Mechanical equipment and transmission device for rapid stop and accurate positioning.
