| Brand Name: | safety |
|---|---|
| Place of Origin: | China (Mainland) |
| Media: | Water |
| Temperature of Media: | Medium Temperature |
| Material: | Casting |
| Power: | Hydraulic |
| Pressure: | Low Pressure |
| Standard or Nonstandard: | Standard |
Quick Details
Specifications
1. the reasons to chooseSafety valve company:1. We Are Factory: Our factory address is: Xinhe Industry Zone,Qingyang,Chizhou City,Anhui,China
2. Regional Sales: We provide specialized sales service refers to different kind of region all over the world. Each sales team member is good at the local language and well experienced to the responsible market. for example: Russian, German, Spanish, Japanese, etc.
3. Low MOQ: Our factory owns the casting company by itself. We are always ready for providing the sample and producing some small orders, in order to meet the business well.
4. OEM Accepted: We can make the products with the client's demand standard or the custom requirement.
Technical Specifications:
Design: DIN3352
Face to face: DIN3202-F4
Flange drilling: DIN2531 / DIN2532 /
DIN2533 / EN1092-2
Main Parts and Material:
| 1 | Body | Cast iron or Ductile iron |
| 2 | Seatring | Cast bronze or stainless steel |
| 3 | Disc | Cast iron or Ductile iron |
| 4 | Bonnet | Cast iron or Ductile iron |
| 5 | Packing | Not asbestos |
| 6 | Gland | Ductile iron |
| 7 | Stem | Stainless steel |
| 8 | Handwheel | Cast iron or Ductile iron |
| DN | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| DN | 1.5" | 2" | 2.5" | 3" | 4" | 5" | 6" | 8" | 10" | 12" |
| L | 165 | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 |
| H | 254 | 267 | 279 | 305 | 406 | 457 | 559 | 711 | 889 | 1117 |
D |
127 | 152 | 178 | 191 | 229 | 254 | 279 | 343 | 406 | 483 |
