Main Technical Variables:

Model	Suitable material	Screw diameter(mm)	Screw L/D length	Blowing film driving motor(kw)	Max.Extrusion output(kg/hr)	Die size(mm)
600mm	HDPE/LDPE	Φ50mm	28: 1	15kw	45kg	60/80mm
800mm	HDPE/LDPE	Φ55mm	28: 1	18.5kw	60kg	80/100mm
1000mm	HDPE/LDPE	Φ60mm	28: 1	22kw	75kg	100/125mm
Width of blowing film(mm)	Thickness of blowing film(mm)	Max.Printing width(mm)	Printing length(mm)	Precision of color printing(mm)	Weight of overall(kg)(two color)	Cover dimensions(lxwxh)(mm)
600mm	0.01-0.06	560mm	250-1000	C: 0.2 L: 0.2	4500kg	8000x2200x4500mm
800mm	0.01-0.06	760mm	250-1000	C: 0.2 L: 0.2	5000kg	8500x2400x5000mm
1000mm	0.01-0.06	960mm	250-1000	C: 0.2 L: 0.2	5500kg	9000x2800x5500mm
