Product features

1.    Completed intelligentized, the Values of the current and resistance of the tested object shall be obtained by Pressing the measure button.

2.    the measure button is also the Self- inspection button.

3.    on-line Self-inspection Function, pressing the self-inspection button for 5s, when the both lights of Self-inspection and measure are on, the tester shall inspect itself and display the value of the self-inspection under the conditions of output circuit of the High-current

4.    the current and measure signal Regardless of the polarity.

5.    the value of the loading Current shall not affect the circuit resistance value of the tested object.

6.    the wide measure range:0—4000μΩ, the First range: 0—400μΩ, the second range: 401—4000μΩ.

7.    Automatic switchover of the Ranges.

8.    the port of the minisize Printer.

Main technical parameters

L  Environmental Temperature: room temperature  relative Humidity:  ＜85%

L  Power supply: AC 220V±10% 50Hz

L  Measurement Range: 0—4000μΩ

L  Video mode: Current and resistance shall be displayed by the four-digit Nixie light

L  Least Resolution Range: 0.1μΩ, Measurement Error: ＜1%

L  Measurement Current: ＞100A

L  Scope of Self-inspection: 100-110μΩ, please refer to the label for the individual self-inspection Value

L  Self-inspection Precision: <0.5%

L  Weight: 8kg, Size: 410mm×260mm×190mm

L  Size: 410mm×260mm×210mm
