| Type: | Multi-Function Packaging Machine |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Dimension(L*W*H): | 1480x1380X1850 |
| Model Number: | LM-BLS720 |
| Brand Name: | longmaker |
| Place of Origin: | China (Mainland) |
| Power: | 3kw |
| Voltage: | 220V/50Hz |
| Driven Type: | Mechanical |
| Automatic Grade: | Automatic |
| Packaging Material: | Paper,Plastic |
| Packaging Type: | Film,Pouch,Stand-up Pouch |
| Application: | Apparel,Beverage,Chemical,Commodity,Machinery & Hardware,Medical |
| Function: | Gluing,Labeling,Slitting,Wrapping |
| Condition: | New |
| Deadwight of machine: | 700kg |
Quick Details
Specifications
730 Color touch screen display, intuitive operation, simple.
PLC computer control system, the operation is more stable, you can not adjust any parameters.
Technical specification:
It can store ten sets of parameters, more accurate replacement of varieties.
Adopt servo motor drawing film vacuum suction membrane, more accurate positioning.
the independent temperature control system, accuracy up to + 1 degrees C.
Independent control of the horizontal and vertical temperature, suitable for various composite film, PE film and other packaging materials.
the packing type diversification, back seal, angle, etc., even punching bag.
the bag making, sealing, packaging, print date in one.
the working environment clean, low noise.
- optional device: even the bag, dust, stiletto, pins, inflatable, "PE" device, automatic correction device;
Technical parameters:
TYPE) |
BLS-720 |
Bag length |
100-500mm(L) |
Bag width |
80-350mm(W) |
Max width of roll film |
720mm |
Packing speed |
5-60bag/min |
Measuring range |
5000ml |
Air consumption |
0.65mpa |
Gas consumption |
0.3㎡/min |
Power voltage |
220V/50HZ |
Power |
5.0KW |
Dimension |
(L)1480mm×(w)1380mm×(H)1850mm |
Deadwight of machine |
700kg |
