| Operating Temperature: | -40-+70 |
|---|---|
| Rated Voltage: | 190-500V AC |
| Capacitance: | 0.5-25UF |
| Package Type: | Surface Mount |
| Application: | Fan |
| Type: | Polypropylene Film Capacitor |
| Model Number: | SH |
| Brand Name: | BSD |
| Place of Origin: | China (Mainland) |
| Certificates: | UL ,Ce ,RoHS ,ISO9001 ,IEC60252 |
| Warranty time: | 3 years |
| Frequency: | 50HZ/60HZ |
| capacitance tolerance: | +-5% |
| Standard: | IEC60252 |
Quick Details
Specifications
1.CBB61 TYPE Capacitor generally use the quadrate anti-flaming plastic shell, epoxy resin packing.
2.this type is of little shape and light weight, little wastage, high insulation resistance, excellent natural repair, good stability, suitable for alternating current circuit.
3.this type capacitor is suitable used in the frequency of 50Hz-60Hz, voltage from 250V -500V single phase A. C. Motors, fan, water pump etc. for starting and running.
4.1-25UF 110-500VAC,50/60HZ
5.UL,CE,ISO9001,IEC60252
2.this type is of little shape and light weight, little wastage, high insulation resistance, excellent natural repair, good stability, suitable for alternating current circuit.
3.this type capacitor is suitable used in the frequency of 50Hz-60Hz, voltage from 250V -500V single phase A. C. Motors, fan, water pump etc. for starting and running.
4.1-25UF 110-500VAC,50/60HZ
5.UL,CE,ISO9001,IEC60252
| Reference standards | GB/T 366.7.1(IEC60252-1) |
| Climatic category | 40/70/21 40/85/21 |
| Class of operation | Class B(10000h) class C(3000h) |
| Class of safety protection | P0 |
| Voltage range | 200-500VAC |
| Capacitance range | 1-35Uuf |
| Capacitance tolerance | +-5% |
| Dissipation factor | 20*10-4 (100HZ,20OC ) |
| Test voltage terminal to terminal UTT | 2Un for 2 seconds |
| Test voltage terminal to case UTC | (2Un+1000)VAC or 2000VAC -50Hz for 60seconds |
| Insulation Resistance | >=3000M uf(100Hz 20 oC,1min) |
