| Type: | Labeling Machine |
|---|---|
| Automatic Grade: | Semi-Automatic |
| Packaging Material: | Glass,Metal,Paper,Plastic,Wood |
| Packaging Type: | Wooden Crate |
| Application: | Commodity,Food |
| Condition: | New |
| After-sales Service Provided: | No overseas service provided |
| Dimension(L*W*H): | (L)1410mm (W)909mm (H)581mm |
| Model Number: | LR110 |
| Brand Name: | AutoPack |
| Place of Origin: | Taiwan |
| Power: | Single Phase 110/220VAC |
| Voltage: | 50/60Hz |
| Driven Type: | Electric |
| Label Length: | 20~300 mm |
| Label Width: | 10~100mm |
| Label Roll: | Inner diemeter 75mm Outer diemeter 300mm |
Quick Details
Specifications
Features
- Height and angle are adjustable
- Horizontal wrap station makes label well attached
- Adjustable labeling and conveyor speed
- Controlled by PLC, touch screen display
- Controlled by PLC, touch screen display Output counter
- Product in-feed and collection trays, Modular design for easy maintenance, quick and easy changeover
- Sanitary SUS#304 and anodized aluminum frame
- Accurate position
- in line application or independent operation
Options
- Hot stamping date coding machine(PE-300, PM-200)/ink jet printer
- LION LDR6300 clear label sensor
Specifications:
- Driven by stepper motor(linear speed: 12M/min)
- Belt width: 95mm
- Label Width: 10-100mm,Length: 20-300mm
- Label Roll: inner diameter 75mm, outer diameter 300mm
- Power: single phase 110/220VAC, 50/60Hz Machine Dimensions: (L)1120mm (W)728mm (H)1130mm (for reference only, the real drawing should be considered as final.)
- Machine Dimensions: (L)1410mm (W)909mm (H)581mm
