| Type: | Character |
|---|---|
| Brand Name: | CNK |
| Interface Type: | SPI |
| Resolution: | 1602 |
| application: | LCD |
| Model Number: | CNK1602-16003A2 |
| Place of Origin: | China (Mainland) |
| Module size(WxHxT): | 66.3x36x9.5mm |
| Display view area(WxH): | 60.8x18.8mm |
| LCD type: | FFSTN/Black/Negative |
| View angle: | 12 O |
| Driver IC: | SPLC780D-003A |
| Backlight Driver type: | LED/White |
| Weight: | 0.022KG |
| Operating Temperature: | -20 to 70 |
| Storage Temperature: | -30 to 80 |
Quick Details
Specifications
CNK Electronics CO.,LTD.
Module size(WxHxT):66.3x36x9.5mm
Display view area(WxH):60.8x18.8mm
LCD type:FFSTN/Black/Negative
View angle:12 O'clock
Driver IC:SPLC780D-003A(or other compatible IC)
Backlight Driver type:LED/White
DC to DC circuit:Build-in
Weight:0.022KG
Operating Temperature:-20C~70C
Storage Temperature:-30C~80C
Drive Method:1/16 Duty,1/5 Bias
Logic Voltage:3.3V
Module size(WxHxT):66.3x36x9.5mm
Display view area(WxH):60.8x18.8mm
LCD type:FFSTN/Black/Negative
View angle:12 O'clock
Driver IC:SPLC780D-003A(or other compatible IC)
Backlight Driver type:LED/White
DC to DC circuit:Build-in
Weight:0.022KG
Operating Temperature:-20C~70C
Storage Temperature:-30C~80C
Drive Method:1/16 Duty,1/5 Bias
Logic Voltage:3.3V
