| Model Number: | SF-4000L-AHD-4G |
|---|---|
| Brand Name: | SF-Tech |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Description:
SF4000L-AHD-4G wireless video uses the latest H.264 video compression algorithm to simulate high-definition AHD video input, while compatible with standard definition video format. Supports 4G dual-card video transmission, special architecture, low-power design, standby power less than 0.5 watts, support SMS, phone, timing and other wake-up mode, user-friendly to start at any time, SMS can directly control the alarm output switch. Can support the national grid platform access, reserved grid encryption chip to encrypt the transmission data, this product can be used for outdoor unattended environment, and other place which wired network is not convenient; Remote channel is stable and reliable, has many means to ensure remote control always being effective.
Key features:
L H.264 / H.265 video compression algorithm
L Two-way voice intercom
L AHD video input, support 1080P / 720P video format, backward compatible with CVBS two-way voice intercom
L Full Netcom module, support 4G dual card binding transmission, support TDD-LTE / FDD-LTE backward compatible with 3G
L TF card local video storage, single card can support up to 64GB
L Low power design, standby power consumption 0.5W
L Telephone / SMS remote wake up, SMS direct control alarm output interface
L Reserved national grid encryption chip interface
L RS485 PTZ control
L RS232 transparent serial port
Details:Type |
Project |
Description |
Audio and video |
Video input |
1 BNC connector, support 1 way AHD video input or 1 CVBS video input; |
Video coding |
H.264/H.265 Compression Support dual stream,rEal-time flow, storage flow SupportCBR,VBR,ABR Video input resolution:1080P,720P,D1 Coding resolution:Real-time stream / storage stream:1080P/720P/VGA/D1/CIF oPtional | |
Audio |
1AUdio input and output; 3.5mm audio interface Input:LINE-IN/MIC optional Output:LINE-OUT Coding:G711U,G711A,ADPCM | |
Memory |
TF card |
Support1TF card storage to128GB; |
Network |
Wireless |
7 modals 4G dual card, support TDD-LTE, FDD-LTE, EVDO, TD-SCDMA, WCDMA three operators' All standards |
Self-locking card slot; antenna external | ||
Wired |
1 RJ45 port | |
I/O Input and output |
6-wayAlarm input |
3 groups drynode input, passive switch alarm input,Default alarm when close |
3 groups wet node input,aCtive switch input,Default alarm in high level(DC5V-25VHigh level,0-3V low level) | ||
6-way alarm output |
2 groups40W, 30V,mAximum current5A | |
4 groups 20W,Maximum voltage24V,Maximum voltage2A | ||
Serial port |
RS232 |
1 RS232 transparent serial port |
RS485 |
RS485,SupportPelco-D,Pelco-P and other protocols,Protocol extended, PTZ Control | |
Power supply |
POwer input |
DC12V/4A A 4-pin terminal,A DC power supply input, both homologous,useΦ5.5*2.1mm |
Power output |
Board external power output 12V,rElay control, default off mAximum load of the relay controlledWithin 10W | |
Power requirements |
Standby mode:0.5W Power consumption:5W | |
Control |
Remote control on / standby |
(1)Timing(2)SMS(3)phone(4)aLarm linkage |
Platform access |
C7 platform |
Support C7 platform access |
State Grid |
Support national grid platform access | |
System |
RESET Button |
INterface:1mm rOund hole; Press and hold the RST key to restore the factory settings |
Watchdog |
Built-in watchdog to ensure 7 * 24 hours normal work | |
Encryption |
Data encryption transmission |
Support the national grid encryption chip to encrypt the transmission data |
Indicator light |
Indicator light |
1 pOwer Indicator:red means sTandby;Green means boot;when light off means shut down 2 4G sTatus indicator (yellow),Indicator flash means dialing,always on means dialing successfully,light off means no card or connection is free |
Physical |
Chassis |
ALuminum alloy;size:L180×W140×H40.5 mm |
Temperature and humidity |
Operating temperature:-40℃-55℃;Humidity:10%-90% |
