Product Main

Quick Details

Brand Name:	Trelink
Input connector type:	N Female
Lightning protection:	DC Ground
Gain(dBi):	9 dBi
Frequency range(MHz):	698~960/1710~2700 MHz
Model Number:	TLYD-627-9V
Place of Origin:	China (Mainland)

Specifications

Electrical Specifications
Model	TLYD-627-9V
Frequency Range	698-960 MHz	1710-2700MHz
Gain	8.2 dBi	9.5 dBi
VSWR	1.8: 1
Polarization	Vertical
Front to Back Ratio	16dB
Horizontal Beamwidth	90
Vertical Beamwidth	50
Input Impedance	50
Maximum Power	100 W
Lightning Protection	DC Ground
Mechanical Specifications
Connector	N female
Antenna Dimension	295*210*65 mm
Weight	0.8 kg /1.7 lb
Radome Material	Weatherproof ABS
Mounting method	Fit with nut
Wind Velocity	210 km/h
Working Temperature	-40~+60
