Applications:

Fixed frequency control circuit, apply to communication products, digital products, energy conservation and environment-protection products, massage equipment, fitness equipment, medical equipment and other household electrical appliances
Product characteristics:

• Safety approval of CCC, CB, ETL, CE, GS, BS, KC, SAA, PSE
• Low standby power consumption, meet the energy efficiency standards of EU CoC V5 and US DoE VI/CEC VI
• Customization: EU standard, American standard, British standard, Australia standard, Korean standards, Chinese standard

 Electrical characteristics:

• Input voltage: 100-240V AC (90-264V AC)
• Input current: 1.5A max
• Frequency: 50/60Hz (47-63Hz)
• Output voltage: 4.6-36V
• Output current: 0.1-5.0A
• No-load power consumption: 0.3W max
• Efficiency: 87% min
• Ripple and noises: 50-200mV
• Line regulation: ±1%
• Load regulation: ±5%

Output protections:

• Short circuit protection
• over-voltage protection
• over-current protection

Environment characteristics:

• Hi-pot test: 3750V AC 60s, 5mA max
• Insulation resistance: 100MΩ min
• Leakage current: 0.25mA max
• Operating temperature: 0 to 40°C
• Storage humidity: 5 to 95%RH
• Burn-in test: rate load, 40 ±5°C, 4 hours
• EMC standards: EN55022 class B/FCC part 15 class B, EN55024/A1:2001/EN61000
