Applications

Fixed frequency control circuit, apply to communication products, digital products, energy conservation and environmental protection products, massage equipment, fitness equipment, medical equipment and other household electrical appliances.

Product characteristics

• Safety approval of CCC, CB, ETL, CE, GS, BS, KC, SAA, PSE
• Low standby power consumption, meet the energy efficiency standards of EU CoC V5 and US DoE VI/CEC VI (6)
• Customization: EU standard, American standard, British standard, Australia standard, Korean Standards, Chinese standard.

Electrical characteristics

• Input voltage: 100-240V AC (90-264V AC)
• Input current: 0.5A Max.
• Frequency: 50/60Hz (47-63Hz)
• Output voltage: 3.0-30V
• Output current: 0.1-2.5A
• No-load power consumption: 0.3W max.
• Efficiency: 75% min
• Ripple & noises: 50-180mV
• Line regulation: ± 1%
• Load regulation: ± 5%

Output protections

• Short circuit protection
• over voltage protection
• over current protection

Environmental characteristics

• Hi-pot test: 3750VAC 60s 5mA max.
• Insulation resistance: 100M Ω min.
• Leakage current: 0.25mA max.
• Operating temperature: 0-40°C
• Storage humidity: 5-95%RH
• Burn-in test: rate Load, 40±5°C 4 hours
• EMC standards: EN55022 class B/FCC Part 15 class B　EN55024/A1:2001/EN61000
•
