Applications

Wireless telephone, routers, Bluetooth products, digital products, mobile phone chargers, battery chargers, electric toy charger, TV box charger, security camera and more.

Product characteristics

• Small volume, streamlined, whole sealing, portability, high cost performance, strong reliability, ultrasonic bonding
• Safety approval of CCC, CB, ETL, CE, GS, BS, KC, SAA, PSE
• Low standby power consumption, meet the energy efficiency standards of EU CoC V5 and US DoE VI/CEC VI (6)
• Accept customization of specification, USB output type or power cord output type.
• Customization: EU standard, American standard, British standard, Australia standard, Korean Standards, Chinese standard.

  Electrical characteristics

• Input voltage: 100-240VAC(90-264VAC)
• No-load power consumption: <0.1W max.
• Output voltage: DC 5.0V-30.0V
• Output power: 0-18W
• Constant-current output: constant voltage output or automatic switch between constant voltage and constant current
• Ripple & noises: <200mV max
• Lightning surge: up to 1KV (accept 3KV)
• Common specification: DC12V/1.0A, 12V/1.5A, 12V/2.0A,
  9V/2.5A

 Output protections

• Short circuit protection
• over voltage protection
• over current protection
• over temperature protection

 Environmental characteristics

• Hi-pot test: 3750VAC 60s 5mA max.
• Insulation resistance: 100M Ω min.
• Leakage current: 0.25mA max.
• Operating temperature: 0-40℃
• Storage humidity: 5-95%RH
• Burn-in test: rate load, 40±5℃, 4 hours
• EMC standard: EN55022 class B/FCC part 15 class B　EN55024/A1:2001/EN61000
•
