Type: | Ventilation |
---|---|
Model Number: | DEC-IA |
Brand Name: | DEC |
Place of Origin: | China (Mainland) |
Diameter Range: | 52mm-610mm |
Temperature Range: | -30 to +150 |
Operating Air Velocity: | 30m/s |
Operating Pressure: | 2500Pa |
Bending Radius: | 0.54xD+25mm |
Color: | Silver out jacket |
Reaction to fire: | Difficult to ignite |
Standard Length: | 10m |
Packing: | Single cardboard box |
Quick Details
Specifications
Thermal Performance 6''X10m Insulated Flexible Foil Duct For HVAC Duct
Introdution:
Insulated Flexible Aluminum Foil Duct: (DEC-IA)(with seamless outer jacket)
the inner flexible duct is aluminum
Foil/polyester covered with 25mm 16kg/m3Fiber glass wool and outer jacket made of aluminum foil and polyester
Film. the outer jacket is seamless.
the insulated aluminum flex duct consists of an aluminum laminate inner duct, thermally insulated with a glass wool layer and provided with an aluminum laminated outer jacket.
the thermal insulation is suitable for
Preventing condensation and minimizing heat loss and loss of cold.
Specifications:
Diameter Range: 52mm~610mm
Temperature Range: -30℃to +150℃
Operating Air Velocity: 30m/s
Operating Pressure: Max.+3000Pa
Bending Radius: Min.0.54×D
Standard Length: 10m
Reaction to Fire: Difficult to ignite
Packing: Single cardboard box
Factory:
Construction
1.Inner duct: AL foil
2.Glass wool blanket: 25mm,16kg/m3
3.R-value: 0.65㎡K/w
4.Outer jacket: twisting seamless AL foil
5.Appearance: silver jacket,PVC jacket
Installation:
Application
L Insulation in air supply systems
L Air conditioning systems
L Thermal insulation in order to prevent heat or cold loss
L Prevention / removal of condensation
Shipping:
