| Brand Name: | CHIKEK |
|---|---|
| Card type: | HitagS 64,HitagS 256, HitagS 2048, EM4100/4200 |
| Communication: | UART TTL |
| Dimension: | 25mmx16.5mmx2.8mm |
| Frequency: | 125KHz/134.2KHz |
| Model Number: | CHK101MT |
| Place of Origin: | China (Mainland) |
| Power: | DC 3.3V -5V |
Quick Details
Specifications
Key Features:
Frequency available with 125KHz, 134.2KHz
3.3V ~ 5V DC Power supply, UART-TTL interface
Compatible withISO11784,11785 Standard, support FDX-B
R/W HITAGS 64, HITAGS 256, HITAGS 2048 tag;
Read only UID of EM4100/4200, TK4100 cards
Available to format HITAGS series card to ID card or FDX-B animal ear tags format;
External antenna, reading range up to 5~7 cm
External LED&BUZ available (external driver circuit needed)
Technical Parameters:
Electrical Specification |
|
Power supply |
DC 3.3V |
Power consumption |
< 45mA |
OPeration frequency |
125KHz &134.2KHz |
Baudrate |
9600~115200 bit/s ( default 9600bps) |
Interface |
UART TTL |
Antenna |
EXternal,Stamp-hole |
Reading range |
50- 100Mm (depends on tag and antenna size) |
Mechanical Specifications |
|
Dimension |
25mmx16.5mmx2.8mm (LxWxH) |
Weight |
3G |
MAterial |
FR-4, Blue |
Model |
CHK101MT |
Environmental Conditions |
|
Operation temperature |
-20C~+80C |
Storage temperature |
-40C~+85C |
Humidity |
Relative humidity5%~95% |
Supported Standard/ Tags |
|
|
EM4100,EM4200, TK4100 |
ISO/IEC 11784/11785 |
HITAGS 64, HITAGS 256, HITAGS 2048 |
SDK information |
|
Demo software |
Windows, C# program language |
Files |
Comprotocol document API document User Manual Demo.Exe |
Note: Other functions and details to be continued and upgraded
