McCoy Global manufactures and distributes high-performance tubular equipment for the oil and gas industry, suited to both workover and drilling applications on land-based and offshore rigs  Main brands: CLINCHER?, FARR?, WINCATT? And GRITFACE?

GRITFACE? Coating for tong dies and handling tool inserts is the choice of energy service companies around the world

Try GRITFACE? Coating for dies and inserts McCoy has been producing GRITFACE? Dies and Inserts

PRODUCT & SERVICES

Tubular Products

Hydraulic Servicing

Dies and Inserts

Jaws and Aftermarket

WINCATT?

1-1/4" Standard Tooth Tong Die

GRITFACE? Tong Die Use with corrosion-resistant alloy (CRA) tubulars

FARR HYD. POWER TONG
14" 50K, MOD. KT-14000
FARR A DIVISION of MACCOY CORP.


Info,
Pmztechnology,
com

1/2 NC HEX NUT 09-9124

3/8 HEX SOCKET SET SCREW * 1/4 NC 09-0107

TORQUE GAUGE MOUNT WELDMENT 101-1783

1/2 NCX1-1/2 HEX SOCKET HEAD CAP SCREW 09-2170

GAUGE MOUNT WELDMENT 101-1621

HITCH PIN 0.148*2.938  09-0090

MOTOR MOUNT WELDMENT 101-1808

3/4 NC*1-3/4 HEXBOLT 09-1292

DOOR WELDMENT (RH) 101-1756

DOOR WELDMENT (LH) 101-1754

DOOR CYLINDER MOUNTING POST 101-1796

3/8 NC 1 SER SCREW 09-1395

SAFETY DOOR LATCH BLOCK AE13-302M

VALVE LOCK NUT 15/16 09-0278

SAFTEY DOOR LATCH BLOCKAE13-301S

DOOR LATCH PLATE AE13-311

3/8 NCX 3/4 HEX SOCKET FHCS 09-4044

SAFTY DOOR GUARD 101-1614

LOAD PLUNGER AE12-306

NPT 1/4-JIC 90DEGREE ELBOW 2024-4-4 08-824

3/8 X 1/2 SHOULDER BOLT 09-9179

CHAIN SLING 101-1343

HANGER BRACKET BASE 101-0361

PEAR CHAIN SLING HANGER 101-0488

3/4 NC*3-1/2 HEX BOLT 09-1300

TORQUE GUAGE, 60000 FT-IBS, 45-1/2 ARM  10-0041G

MOTOR, RINEER, 37 SERIES, 26 CID, KEYED 87-0130

SNAP RING-SEAL PLATE 0370111

O-RING SEAL PLATE 0370114

FRONT HOUSING, A, PC 0371123

O-RING, THERMAL, INNER 0370811

O-RING, thermal, middle 0371829

O-ring, thermal, outer 0370810

MAIN O-RING 0370810

PLATE SCREW 0150620

PLATE, TIMING, PC 0370618

DOWEL PIN 0370431

STATOR, GA37 0370400

STATOR VANE SPRING 0370420

ROTOR 0370300PC

ROTOR 0370300PL

ROTOR VANE SPRING OUTER 1250320

ROTOR VANE SPRING INNER 1250321

REAR HOUSING, A, PC 0370883

BOLT 0370910

SQUARE SEAL for PARALLEL LO-BOY VALVE SECTION 02-0080

SQUARE SEAL for PARALLEL LO-BOY VALVE SECTION 02-0081

BACK CAP SCREW 02-0084S

BACK CAP 02-0084

RETAINER PLATE 02-0086

BACK-up RING  02-0087

SPOOL SEAL 02-0088

RETAINER PLATE SCREW 02-0086S

CHECK VALVE CAP ASSY (CONTAIN O-RING SEAL, SPRING, POPPET) SDS 07-0004
McCoy Farr KT8625 Power Tong - 8-5/8"
Description Specification
Size range 2.375" to 8.625"
Hydraulic power supply 2,200 psi and 60 gpm
Max low gear torque and speed 25,000 ft.-lb. and 12 rpm
Max high gear torque and speed 5,000 ft.-lb. and 58 rpm
Tong handle length 36"
Overall tong length 53"
Overall tong width 26"
Overall tong height 46.750"
Overall tong weight 1,550 lb. (2,750 lb. with CLINCHER? Backup, 2,550lb. with FARR Cam Style Backup and 4,600 lb. with FARR Mounted Wedge Backup)
