| Model Number: | SF-5015DT |
|---|---|
| Brand Name: | SF-Tech |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
| Detail | ||
| CPU | Atheros AR9342 (560MHz) | |
| RAM | 64MB DDR2 | |
| ROM | 16MB | |
| Power supply | ||
| Power method | 24V PoE | |
| Power | 5W | |
| Environment | ||
| Temperature | Operating temperature:-20oC to 70oC Storage temperature: -40oC to 90oC | |
| Humidity | Operating humidity: 5% to 95% (Non-condensing) Storage humidity: Max.90% (Non-condensing) | |
| Wired | ||
| Wired network | Two RJ45 interfaces | |
| Transmit power and receive sensitivity | ||
| Transmit power | Data transfer rate | 5GHz(Summary) |
| HT20 MCS0 | 22dBm | |
| HT20 MCS7 | 16dBm | |
| HT40 MCS0 | 21dBm | |
| HT40 MCS7 | 16dBm | |
| Receive sensitivity | Data transfer rate | 5GHz |
| HT20 MCS0 | -94dBm | |
| HT20 MCS7 | -72dBm | |
| HT40 MCS0 | -90dBm | |
| HT40 MCS7 | -70dBm | |
| Antenna | ||
| Gain | 15dBi | |
| Direction | Orientation | |
| Frequency Range | 5.1-6.1 GHz | |
| Polarization | Dual polarization | |
| -3dB Azimuth beam width | Horizontal (port1): 32° Vertical (port2): 35° | |
| Horizontal beam width (directional shaping) | Horizontal(port1): 15° Vertical(port2): 17° | |
| Isolation | -37dB (Max) | |
| Before and after | -35dB (Max) | |
| Standing wave | Horizontal(port1): < 1: 1.87; Vertical(port2): < 1: 1.55 | |
| Cross polarization isolation | -26dB (Max) | |
| Sidelobes | <-12dB | |
| Physical parameters | ||
| Size | 223 x 123 x 60 mm | |
