·Features
1. Patent gradient mixer, has high performance, dead volume <10μL.
2. Dual piston reciprocating and series pump. One is a main adsorption piston; the other is an assistant piston, to make the flow stable.
3. the detector use 24 bits AD transducer, to ensure low noise, low drift and high sensibility. Having auto-detection when starting up, can check and set the deuterium lamp status.
4. Using International advanced high pressure injector technique. the quantify injector, mobile phase pass through injection, computer control for the sample volume can reduce residual sample. It can change the sample input volume without replacing the quantify hoop conveniently.
5. Beautiful and convenient surface. Stand-alone color screen touch control. Each unit has 16:9 TFT color screen, which support imputing and displaying for all information through instrument touch screen when offline.
6. Powerful control function with intelligent anti-control Software. High-level imitating anole chromatogram processing software with data acquisition interface. It's very convenient for customer to operate in one key. Powerful auto data analysis function ensures your sample analysis, data display, data analysis and report efficiently.
·Specification

LC600-P02 High-Pressure Gradient Pump
Peak Operating Pressure	45Mpa,Stainless Steel Pump
Pressure Error	±0.02MPa
Flow Rate Range	0.001-9.999mL/min
Flow Rate Precision	±5%
Flow Rate Repeatability	RSD≤0.1%
Power	220v±10%,50Hz,250W
Size	520mm x 420mm x 160mm(W*H*D)
LC600-D01 UV Detector
Wavelength	190-680nm
Wavelength Error	≤±1nm
Baseline Noise	≤2 x 10-5AU(Methyl Alcohol, 1mL/min, 254nm, 20oC)
Wavelength Repeatability	0.2nm
Flow Cell	8μL
Drift	≤5 x 10-4AU/h(Methyl Alcohol, 1mL/min, 254nm, 20oC)
Limit of Detection	≤2 x 10-9G/mL(Naphthalene Methyl Alcohol Solvent)
Automatic Injector
Sample Value	Maximum 2mL,6 x 25=150units
Sample Volume	0-1mL, Adjustable
Sample Residual	<0.02%
Column Oven
Temperature Control	Room Temperature+5oC-80oC
Constant Temperature Accuracy	±1oC
Constant Temperature Precision	≤0.1oC
Temperature Setting resolution ratio	0.1oC
Overall Instrument
Qualitative Analysis	RSD6≤0.2%
Quantitative Repeatability	RSD≤0.2%
Sample Residual	≤0.01%
Gradient Error	≤0.5%

·Application
Medicine analysis, food safety, environmental detection, oil and chemical analysis, animal and aquaculture, colleges and universities, scientific research and so on.
