| 1.Totally EU streamlined design,Monoblock by welding robots & aparatus and stress relief process by Annealing treatment. |
| 2.Accurl engineers utilize parametric 3D SolidWorks using FEM & DOE analysis as well as static and mechanism analysis. |
| 3.Accurl Hydraulic Shearing Machine is a Swing Beam Action machine which is produced in a variety of cutting lengths and capacity options. |
| 3. Adopt integrated hydraulic system, more reliable and easy for maintenance. and the hydraulic system from Bosch-Rexroth, Germany, |
| 4. Equipped with lighting-alignment, so as to align when shearing. the stroke of knife beam can be adjusted in stepless mode. |
5. Hydraulic drive, return of knife beam is smooth and prompt by nitrogen cylinder. |
| 6. CE conformity including Tiltable Fornt Finger Guard and Optical Rear Safety Guard, |
7. Safe fence and the electric interlocker have been designed for the machine to ensure the operation safety. |
| Standard Equipment: |
| 1. Rapid and precise blade clearance adjustment by single handle on the side frame |
| 2. Multi Edge Blades for cutting Aluminium, Mild Steel and Stainless Steel |
| 3. Cutting Line Illumination and wire for shadow line cutting |
| 4. Counter of Strokes, Cutting Length Adjustment |
5. Hydraulic and Electrical overload protection |
6. Squaring Arm and Front Support Arms |
7. Estun E21 NC control |
| 8. Germany Bosch-Rexroth Hydraulic |
| 9. Telemecanique/SchneiderElectrics |
| 10. Hydraulic and Electrical overload protection |
11. Delta inverter with ball screw and polished rod with 0,05 mm accuracy. |
12. Side guard is standard meeting CE regulations. |
|
Better Cuttings: |
1.Backgauge adjustment according to blade gap. |
2.Backgauge retraction feature. |
3.Sub-program and programming loop. |
4.Sequence repeat function. |
5.Auto cutting (Flying cut). |
| Estun E21s NC Shearing Machine Control system: |
| 1. Monochrome LCD Box Panel. |
| 2. Integral factor programmable freely |
| 3. Automatic Positioning control |
| 4. Spindle allowance offset |
| 5.Internal time relay |
| 6.Stock counter |
7.Backgauge position display, resolution in 0.05mm |
the best cutting results You can cutt longer and narrow parts with standard AC/MS7-Cutt Series. |
