| Output Power: | Max 180 W@100% Load |
|---|---|
| Output Voltage: | ATX(+12V,+5V,-12V,+3.3V,+5VSB) |
| Input Voltage: | 11.4V/DC~12.6V/DC |
| Model Number: | M-MPS |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Specification:
Temperature: Operating temperature:0?C ~ +40 Storage temperature:-20?C ~ +80?C
Humidity: Operation humidity:0% to 85%;Storeage humidity:10% TO 90%
Input & Output Voltage: Input voltage:11.4V/DC~12.6V/DC;Output voltage:ATX(+12V,+5V,-12V,+3.3V,+5VSB)
Power: Max 180 W@100% Load
Efficiency: the converter efficiency should not be less than 94% at the maximum load
Dimensions: 55.0mm(L)*15.0mm(W)*37.5mm(H)
PCB size & Material: PCB size: 55.0mm*27.0mm*1.6mmPcb material:FR-4Pcb layer:4
Weight: the converter weight:about 57 grams
Temperature: Operating temperature:0?C ~ +40 Storage temperature:-20?C ~ +80?C
Humidity: Operation humidity:0% to 85%;Storeage humidity:10% TO 90%
Input & Output Voltage: Input voltage:11.4V/DC~12.6V/DC;Output voltage:ATX(+12V,+5V,-12V,+3.3V,+5VSB)
Power: Max 180 W@100% Load
Efficiency: the converter efficiency should not be less than 94% at the maximum load
Dimensions: 55.0mm(L)*15.0mm(W)*37.5mm(H)
PCB size & Material: PCB size: 55.0mm*27.0mm*1.6mmPcb material:FR-4Pcb layer:4
Weight: the converter weight:about 57 grams
