Vertical Bending MachineVertical Bending Machine

DW38NC vertical bending machine details:

DW38NC vertical high-speed single-head hydraulic bending machine, bending speed, especially for aluminum processing, the use of

NC control, multi-group program, multi-angle setting, so your simple side.

Key Specifications unit Models: DW38NC vertical tube bender Remarks
Maximum bending diameter × wall thickness mm Φ38 × 2

1. Minimum bending radius according to pipe diameter

2. Maximum bending radius according to customer requirements

3. Maximum core length of wear based on customer requirements

Maximum bending radius mm R260
Minimum bend radius mm R15
Maximum bending angle Degree 190
Standard straight-length mm 1600
Control system
Microcomputer control
Elbow pipe to allow the number of Unit 16
Parts store a few Unit 16 × 16
Hydraulic motor power KW 4
System pressure Mpa 12
Hydraulic system control
Solenoid valve)
Tank capacity L 110
Overall size mm 2600 × 600 × 1000
Machine weight Kg 750
