SPECIFICATIONS:
Key Specifications |
Models: DW130CNC-7A-4S | Notes | |
| Maximum bending diameter × wall thickness | Φ130mm × 8mm | 1. Minimum bending radius according to pipe diameter 2. Maximum bending radius according to customer requirements 3. Maximum core length of wear based on customer requirements | |
| Maximum bending radius | R400mm | ||
| Minimum bend radius | R50mm | ||
| Maximum bending angle | 190 ° | ||
| Maximum feed length | 3000mm | ||
| Feeding | Direct- pinch | ||
| Pace of work | Bending speed | Max 30 ° /s | |
| Rotary speed | Max 160 ° /s | ||
| Feeding rate | Max 800mm /s | ||
| Working precision | Bending precision | ± 0.15 ° | |
| Rotary precision | ± 0.1 ° | ||
| Feeding accuracy | ± 0.1mm | ||
| Information input | 1. Coordinates (X. Y. Z) 2. Work value (YB C) | ||
| Bending mode | Hydraulic pipe | ||
| Rotary servo motor power | 2kw | ||
| Feeding servo motor power | 5kw | ||
| Elbow pipe to allow the number of | 1. 12 2. 33 | ||
| Parts store a few | 1. 330 2. 125 | ||
| Hydraulic motor power | 22kw | ||
| System pressure | 12 Mpa | ||
| Machine size | 6115 x 1860 x 1265mm | ||
| Weight | 8000kg | ||
