| Insulation Material: | PVC |
|---|---|
| Conductor Material: | Copper |
| Application: | XLPE PVC Insulated Control Cable |
| Brand Name: | Gongyi Cable Wire Co., Ltd. |
| Type: | XLPE PVC Insulated Control Cable |
| Jacket: | PVC |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
XLPE PVC Insulated Control Cable
Introduction
XLPE PVC insulated and sheathed control cable has a very good property for resistant causticity of chemical solvent. It is used as a connecting wire of electrical equipment and Instrument, transmitting wire of automatic control system for rock oil, chemical, electric power, metallurgical and so on with rated voltage up to Uo/U 450/750V. It is manufactured according to GB/T9330-2008(idt.IEC227) standards.
Features
1. Rated AC Voltage: Uo/U:450/750V
2. Long-term permitted operating temperature of conductor for PVC insulation cables is 70℃, 90℃ and 105℃; for Halogen-free and low smoke flame-proof cables is 70℃; for XLPE insulation cables is 90℃.
3. the lowest environment temperature for PVC insulation and sheath, the fixed deploying is -40℃ and Non-Fixed deploying is-15℃.
4. the Mounting deploying temperature: for PVC sheath should above 0℃.
5. the Permitted minimum bending radius:Not smaller than 12 times outer diameter for copper tape shield or steel wire winding and 6 times outer diameter far other cables.
