| Rated Voltage: | 15kv/9kv |
|---|---|
| Capacitance: | 50PF |
| Package Type: | Surface Mount |
| Application: | Hight Voltage |
| Type: | Vacuum Capacitor |
| Model Number: | CKT50/10/27 |
| Brand Name: | GLVAC |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
High quality capacitor for high current applications
Replacement for low current applications with long lifetime
Low internal inductance for operation in excess of 100 MHz
Uniform size Unique rugged and cost-effective design
Widely used in different applications like matching networks
DC blocking and RF sealing
Optional extension rods for easy replacement.
the vacuum capacitor Cross reference
COMET Old Type: MC1C-50E/15
COMET New Type CFMN-50CAC/15-AF-G
| Specification | |
| Capacity Cmax(nominal) | 50PF |
| Voltage(peak test Upt/peak Working Upw) | 15kv/9kv |
| Capacity to tolerance | 10% |
| Max.Current Imax at 13.56MHZ with | 27Arms |
| Conduction cooling | 20W |
| Net weight | 0.35kg |
