DESCRIPTION

                            Container Semi-Trailer

MAKE

LiangXiang

MODEL

SPECIFICATIONS

PARAMETER

OVERALL

DIMENSION

(mm)

Length

12500

Width

2500

Height

1680

WEIGTH

RATING

(kg)

Kerb. Weight

7200

Payload

45000

Total Mass

52200

WHEELBASE (mm)

6830+1310+1310

MAIN FRAME

DESCRIPTION

Heavy duty and extra durability designed high tensile steel Q345B, welded by automatic Submerged-Arc processes 500mm height Beam

TOP FLANGE (mm)

16 mm Width

MIDDLE FLANGE (mm)

8mm

BOTTOM FLANGE (mm)

16 mm Width

PLATFORM

STRUCTURE

(mm)

Front & Rear

-

Right & Left

-

Floor

3mm

SUSPENSION

Type

One Couple of Tri-axle Mechanical Suspension

DESCRIPTION

Six Sets of 10 pieces 13x100mm leaf spring

AXLE

MAKE & BRAND

Fuwa alxe

WEIGHT RATING & TOTAL AXLE

13000kg x 3

KINGPIN

TYPE

One unit of #90 SAE standard welded Kingpin

LANDING GEAR

TYPE

2 Speed, manual operating, heavy duty landing gear

BRAKE SYSTEM

TYPE

A system with emergency brake and parking brake; Dual line- air brake,piggyback spring on all axles;Two units of WABCO RE 4 relay valve(or equivalent); Four units of T30/30 spring brake chamber; Two units of T30 brake chamber, two units of 40L air tanks; two units of standard copper air-connector.

TIRE & RIM

RIM SIZE X NUMBERS

8.5 -20 x 12 pieces

TYRE TYPE & SIZE X NUMBERS

11.00R20 x 12 pieces

SPARE WHEEL CARRIER

One set of spare wheel carrier

ELECTRICAL SYSTEM

VOLTAGE

24 volt standard 7 pin plug SAE / ISO1185 socket, support from tractor

ELECTRICAL APPLIANCES

Tail lamp with turning signal, brake light & reflector, Side lamp etc. One set of 6-core standard Cable

FINISHING

COATING

Sand blasting processing on rust– proof protection.. One coat of anti corrosive primer

PAINTING

Two(2) coat of finishing paint, body color and black color flame

ACCESSORIES

STANDARD

One tooling box with a set of standard trailer tool
