Description:
Small contact stroke, small size, light weight, low operating power, quick, short arcing time. Isolation performance of the contacts is good after arc-extinguishing, failure capability is better around breaking area; slight combustion loss when breaking the current of contactors, long life, low noise; Used in high frequency operation.

Product Details Introduction

Technical Parameters
Rated voltage	V	1140(660)
Rated current	A	400
Ultimate making capacity	kA	7.5(9)
Inherent opening time	ms	≤30
Inherent closing time	ms	≤100
Closing Bounce time	ms	≤2
Mechanical life	Times	2×104
Electrical Life	Times	3×103
Weight	kg	18
Closing power supply voltage	V(AC)	127
under-voltage, shunt DC current	V(DC)	48
Closing power	W(transient)	1152
Opening power	W	31
under-voltage power	W	5
Auxiliary contact	4 pairs NO, 4 pairs NC
Auxiliary contact capacity	Ue:AC380V Ie:10A
