| Brand Name: | GLVAC |
|---|---|
| Size: | 36*100mm |
| Type: | Interrupter |
| Material: | ceramic |
| Color: | white |
| Model Number: | TJ-1.14/125A |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Description: =120 20±3 3 1.8±0.2 1±0.2 =3 =1
the Interrupter adopts 'one shut technology'ceramic shell, CuWC as the contact material;is characterized by high insulation, low stop-flow, strong blowout ability, long life, smallsize etc, and has advantages as easy to maintain, no explosion risk,pollution-free and lownoise etc. Contactors assembled by it are used to control and protect the electricity transmission and distribution system in electrical, mechanical, chemical, metallurgy, mining and railway department, especially in frequent operation fields.
Product Details Introduction
Model
TJ-1.14/125A Rated Voltage
KV
1.14 Rated Current
A
125 Rated Make Current
KA/times
1.25/50 Rated Break Current
KA/times
1/50 Maximum Break Current
KA/times
2.5/3 Rated Short Time Withstand Current/Last Time
KA/s
1/10 Break Times under Rated Current
AC-4
6×104 Short Time
Power Frequency Withstand Voltage1Min
V10 Thunder and Lighting Shock
KV
Circuit Resistance under Rated Contact Pressure
ΜΩ
Mechanical Life
Times
1×106 Contact Force at Rated Contact Gap
N
Max Contact Gap
mm
Reaction Force at Rated Contact Distance
N
60±10 Contact Erosion Limit
mm
1 Weight
Kg
0.25 Store Duration
Year
10 Mechanical
ParameterRated Contact Gap
mm
Contact Overtravel
mm
Average Break Speed
m/s
0.3~0.5 Average Make Speed
m/s
0.05~0.15 Rated Contact Operating Pressure
N
80 Contact Make Bounce Time
ms
Three-phase Synchronism
ms
