| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Weight: | According to different size |
| Power(W): | According to different size |
| Brand Name: | CX |
| Condition: | New |
| Warranty: | Three years life |
| Certification: | ISO9001,SGS,CE |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Name:Waste tire recycling machine,Waste tyre recycling machine,Tire shredder,Tyre
Shredder,Tyre crusher,Tire crusher,tyre recycling line
Application: Crush the waste tire into rubber powder with advantage of environmental protection and energy saving, bright market prospect.
1. Tire Cutter: It is the first process of reclaiming waste tire, used to separate among the tire crown, side-wall and bead.
Highlights: the blade is excellent hardened alloy for wearing-resistance and long life.
Parameter:
2. Strip Cutter: It is mainly used in cutting the crown and side-wall of waste tire into certain width of rubber strip.
Highlights: the two disc knife adopts special metal heat treatment with high hardness and durability.
Parameter:
3. Block Cutter: It is mainly used to cut the rubber strip in to block.
Highlights: the blade adopts excellent hardened alloy for wearing-resistance and long life.
Parameter:
4. Bead Wire Separator: It is mainly used in separating rubber and steel wire of bead.
Highlights: Easy operation, Simple Maintaince.
Parameter:
5. Transportation System: Belt Conveyor + Vibrating Sieve + Magnetic Separator.
6. Rubber crusher Machine:
Main Features:
A. Grooved & Smooth Roller: Chilled casting iron alloy.
B. Emergency brake device: Manual and automatic.
C. Famous motor.
D. Durable transmission system.
E. Esay assembly and operation.
F. CE, ISO approved.
Parameter:
Note:
1. for rubber cracker, there are three types, you can seletct the suitable one as the output requirement.
2. for grinder, if final rubber powder bigger than 30 mesh, no need to equip it. If the powder less than 30 mesh, need to equip it. and the quantity depends on the output.
Shredder,Tyre crusher,Tire crusher,tyre recycling line
Application: Crush the waste tire into rubber powder with advantage of environmental protection and energy saving, bright market prospect.
1. Tire Cutter: It is the first process of reclaiming waste tire, used to separate among the tire crown, side-wall and bead.
Highlights: the blade is excellent hardened alloy for wearing-resistance and long life.
Parameter:
| Production Capacity (Pieces/Hour) | 60-80 |
| Motor Power (KW) | 3 |
| Motor Rotating Speed (R/Min.) | 1440 |
| Dimension (MM) | 1300x900x1200 |
| Weight (KG) | 300 |
2. Strip Cutter: It is mainly used in cutting the crown and side-wall of waste tire into certain width of rubber strip.
Highlights: the two disc knife adopts special metal heat treatment with high hardness and durability.
Parameter:
| Production Capacity (KG/Hour) | 1500-2000 |
| Motor Power (KW) | 5.5 |
| Motor Rotating Speed (R/Min.) | 1440 |
| Model of Reducer | 350 |
| Reduction Ratio | 31.5 |
| Size of Discharged Materials (MM) | 20-50 |
| Dimension (MM) | 1300x700x1500 |
| Weight (KG) | 670 |
3. Block Cutter: It is mainly used to cut the rubber strip in to block.
Highlights: the blade adopts excellent hardened alloy for wearing-resistance and long life.
Parameter:
| Production Capacity (KG/Hour) | 1200-1500 |
| Motor Power (KW) | 7.5 |
| Motor Rotating Speed (R/Min.) | 1440 |
| Size of Discharged Materials (MM) | 20-50 |
| Dimension (MM) | 750x750x1200 |
| Weight (KG) | 420 |
4. Bead Wire Separator: It is mainly used in separating rubber and steel wire of bead.
Highlights: Easy operation, Simple Maintaince.
Parameter:
| Production Capacity (Pieces/Hour) | 70 |
| Motor Power (KW) | 15 |
| Motor Rotating Speed (R/Min.) | 1440 |
| Model of Reducer | 400 |
| Reduction Ratio | 40.17 |
| Dimension (MM) | 1500x900x1400 |
| Weight (KG) | 1300 |
5. Transportation System: Belt Conveyor + Vibrating Sieve + Magnetic Separator.
6. Rubber crusher Machine:
Main Features:
A. Grooved & Smooth Roller: Chilled casting iron alloy.
B. Emergency brake device: Manual and automatic.
C. Famous motor.
D. Durable transmission system.
E. Esay assembly and operation.
F. CE, ISO approved.
Parameter:
| Parameter \ Model | XKP-560 | XKP-450 | XKP-400 |
| Front roller diameter (MM) | 560 | 450 | 400 |
| Back roller diameter (MM) | 510 | 450 | 400 |
| Roller length (MM) | 800 | 650 | 600 |
| Front roller surface speed (m/min) | 25.56 | 23.2 | 17.32 |
| Friction ratio | 1:1.3 | 1:1.38 | 1:1.38 |
| Max. Nip | 15 | 8 | 8 |
| Feeding capacity (KG/H) | 1500 | 600-800 | 200-300 |
| Motor power (KW) | 75 | 55 | 45 |
| Measurement (MM) | 5064x2284x1978 | 4770x1846x1835 | 3950x1800x1780 |
| Weight (KG) | 19000 | 19000 | 19000 |
Note:
1. for rubber cracker, there are three types, you can seletct the suitable one as the output requirement.
2. for grinder, if final rubber powder bigger than 30 mesh, no need to equip it. If the powder less than 30 mesh, need to equip it. and the quantity depends on the output.
Sl. No. |
Description | Model No. | Quantity |
| 1 | Ring cutter | QQJ-20 | 1 |
| 2 | Strips cutter | QTJ-380 | 1 |
| 3 | Rim cutter | QKJ-45 | 1 |
| 4 | Loop machine | YQJ-285 | 1 |
| 5 | Conveyor equipment | BSJ-1100, XSJ-600 | 2 |
| 6 | Rubber cracker | XKP400/XKP450/XKP560 | 1 |
| 7 | Magnet separator | BCX-2, XCX-1 | 2 |
| 8 | Vibrating screen | BS-8, XS-4 | 2 |
| 9 | Nylon separator | XFJ-1100 | 1 |
| 10 | Rubber grinder | XMF-270/330/420 | 1 |
