| Application: | Agricultural UAV |
|---|---|
| Nominal Capacity: | 13000mAh |
| Voltage: | 22.2v |
| Type: | LI-PO |
| Brand Name: | SHIDA BATTERY / AP |
| Weight: | 1.18KG |
| Size: | 60*73*163MM |
| Components: | LI-PO battery cell, plugs, wires |
| Composed Type: | 6S1P |
| Model Number: | 6*9470170MP-13000 6S1P |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Product details:
Warranty
SHIDA BATTERY TECHNOLOGY will be responsible for replacing the cell against defects or poor workmanship for 12 months from the date of shipping. Any other problem caused by malfunction of the equipment or mix-use of the cell is not under this warranty.
Remarks:
the aluminum packing foil is very soft that it will be easily left scratches. Please do not hit the cell with any sharp edge parts.
Don't fall, hit or bend the battery. It may cause fire or explosion.
Short circuit the battery is strictly prohibited; it may damage the battery seriously.
Never disassemble the battery. It may cause fire.
Never dispose of the battery in fire. It is very dangerous and strictly prohibited.
to immerge the battery into liquid such as water is strictly prohibited.
Avoid vibration, shock or extrude the battery. Handle carefully when moving it.
Storage for a long time If the cell is kept for a long time(3months or more), It is strongly recommended that the cell is preserved at temperature range(0-25oC),low humidity, no corrosive gas atmosphere.
More information,contact us
| Capacity: |
13000mAh |
| Voltage: | 22.2V |
| Wh: | 288.60Wh |
| Dimension: | 60*73*163mm |
| Discharging C Rate: | over 50C continuous, over 80C burst |
| Charging C Rate: | 3C~8C |
| Extra Run Time: | over 500 times |
| Charging Plug: | JST-XH/selected |
| Discharging Plug: | XT90, XT60 ect. |
| Technology: | Korean tech, Nano tech, High voltage tech |
| Charging temperature: | 0 C ~ +45 C |
| Operating temperature: | -10 C ~ +70 C |
| Precision-balanced: | High standard matching cells |
| Application: | UAV,drone, UAV crop sprayer |
| Others: | Higher MP(Medial Platfo of Voltage), thinner |
| Certificates: | ROHS, UL, UN38.3,CE |
| OEM provided | Yes |
Warranty
SHIDA BATTERY TECHNOLOGY will be responsible for replacing the cell against defects or poor workmanship for 12 months from the date of shipping. Any other problem caused by malfunction of the equipment or mix-use of the cell is not under this warranty.
Remarks:
the aluminum packing foil is very soft that it will be easily left scratches. Please do not hit the cell with any sharp edge parts.
Don't fall, hit or bend the battery. It may cause fire or explosion.
Short circuit the battery is strictly prohibited; it may damage the battery seriously.
Never disassemble the battery. It may cause fire.
Never dispose of the battery in fire. It is very dangerous and strictly prohibited.
to immerge the battery into liquid such as water is strictly prohibited.
Avoid vibration, shock or extrude the battery. Handle carefully when moving it.
Storage for a long time If the cell is kept for a long time(3months or more), It is strongly recommended that the cell is preserved at temperature range(0-25oC),low humidity, no corrosive gas atmosphere.
More information,contact us
