Specification.

1. Thermal performance, Such as 400W. Test and load 350W, work for four hours, the surface temperature was arround 45 degrees.
2. Output voltage stability,
2.1.the gap between no-load voltage and full load voltage is only 2V.Control within 5V
2.2When Input voltage 15V and 10V input voltage testing, the output voltage is between 216-218V, the gap is only 2V. Control within 5V
3. Floating frequency within 1HZ. so that more stable for work with the load equipment
4. for inductive load, peak power can be up to 3 times.
5. Protection function, especially overload protection will automatically shut off after alarm three times, if didnt cut down the load by hand the inverter will cutoff automatically, You need to re-open switch if you want it work.
6. with reverse polarity protection.
7. CPU control with low rate of repaire.
8. You can load Power Tools: drills, grinding machines, motors, gates, refrigerator, freezer.CTR older TVs and LCD screen TV. this is a lot of ordinary inverters can not do.



Specification:

Model	800W	1000W	1200W	1500W	2000W	2500W	3000W
Continous power	800W	1000W	1200W	1500W	2000W	2500W	3000W
Max power	1600W	2000W	2400W	3000W	4000W	5000W	6000W
Input voltage	12V
Output Voltage:	220Vac(50Hz) or 110Vac(60Hz)
Waveform	Modified sine wave
Efficiency	87-90%
Input under Voltage Warning	10.5Vdc±0.5
Input under Voltage Shutdown	9.8Vdc±0.5
Input over Voltage Warning	15Vdc±0.5
Input over Voltage Shutdown	15.5Vdc±0.5
Input Fuse Protection	Yes
High temperature protection	Yes
Output short circuit protection	Yes
Overload protection	Yes
Release Protection	Yes
