Application:

DSP Coalescence-separation oil purifier is designed to remove free water and dissolved water from lube oils or diesel fuel,coalescing filter will make the free and dissolved water from small molecule to big drop, then separation filter remove the water drop by gravity, falling into the water tank. It removes the particles by stages of filters and cleanness up to NAS grade 6. It is applicable for on line running with light oil filled, turbine oil filled and lubricating oil filled systems, especially good for water- leakage systems.



Features:

1. Rapidly removing large amount free & emulsified water from Oil and water content reach 100 PPM.

2. Thecoalesced oil takes the least restricted path to exit and rises or floatsthrough the media to the top of the bulk liquid surface.

3. the working conditions of all the parts are displayed clearly, monitoring, alarming, action control and safety stop enable the oil filtration machine to run online.

4. Multilayer filtration can remove the impurities through coarse filter, protecting filter, and fine filer.

TechnicalSpecification



Model		DSP010	DSP020	DSP030	DSP050	DSP100	DSP150	DSP200	DSP300
Capacity(L/min)		10	20	30	50	100	150	200	300
Working pressure		≤ 0.4 Mpa
Filtering precision		≤1 micron
Water content		≤100 ppm
Cleanness level		NAS 6 grade
Continuous work		≥200 hr
No failure running		≥5000 hr
Power supply		380V, 50HZ, 3PH ( or Customized )
Working noise		65 dB
Total power (kw)		1	1	1	2	2.5	3	4	5
Inlet/outlet(mm)		32	32	32	32	44	50	58	65
Weight (kg)		300	350	400	450	520	760	900	980
Dimension (mm)	L	1200	1300	1400	1500	1600	1650	1650	1750
	W	750	800	900	950	1000	1050	1100	1200
	H	1400	1500	1550	1600	1650	1700	1750	1850
