Application

PR-Series plate pressure oil purifier is designed for power plants, industrial and mining substations, lubricants warehouse, tractor station, petroleum, chemical, cement, metallurgy etc. It can purify transformer oil, turbine oil, hydraulic oils, gear oils, lubricating oil and remove water, mechanical impurities. PR plate pressure oil purifier is consisted of filter bed, plates, oil pump, motor and filtering papers. the filter bed and plates consist of a filter house, between the plates, the papers as filtering media. It also can purify fuel oil, cooking oil by using special materials and motor. PR-series oil purifier has a simple structure, convenient filter replacement, high filtration precision, easy operation, low cost.





Technical specification:



Model			PR030	PR050	PR100	PR125	PR150	PR200	PR300
Capacity( L/min)			30	50	100	125	150	200	300
Working pressure (Mpa)			0～0.4
Filtering space (㎡)			0.48	0.6	1.57	1.88	2.35	3.14	4.08
Plate size (mm)			180×180			280×280
Filter paper size (mm)			180×180			280×280
Filtering precision			≤ 1 micron
Pressure type			Manual type
Filter ring quantity			6	8	10	12	15	20	26
Filter plate quantity			7	9	11	13	16	21	27
Motor	Power (KW)		1.1	1.5	2.2			3	4	5.5
	Speed (r/min)		1400	1400	1400			1400	1400	1400
Inlet caliber			1			1 1/4						2 1/2
Outlet caliber			3/4			1 1/4						2 1/2
Dimension (mm)		L	800			820			900	1150	1200
		W	300			410			410	430	450
		H	650			850			850	920	950
Weight			150	185	280	295	320	330	350
