Some of their technical data as follow:



Application scope		220kvtranssmission Line
Tower Name	Suspension tower	Tower type	LVZT
Design condition		Nominal height(m)	Steel weight(kg)
Conductor Type	2×LGJ-185	15	1413.4
Earth Wire type	GJ-50	18	1920.4
Max.Wind Speed(m/s)	28	21	2287.2
Max.Ice(mm)	5	24	2454.0
Horizontal Span(m)	480	27	2646.4
Vertical Span(m)	650
Angle



Remark: above technical data only References for our client, we can design every type for our overseas clients.



MEGATRO is a full service engineering company with a global Reputation for delivering excellence and innovation in power transmission, Transformation, distribution, and telecommunications systems. Our MEGATRO provide and design this type 220KV Transmission line LVZT type suspension tower, mainly for our overseas client. since 2004, MEGATRO focus Mainly international market and had export many kind of transmission structures To overseas clients. MEGATRO has been manufacturing lattice transmission tower & tapered steel poles for lighting, traffic control, communication and Utility applications. MEGATRO pioneered the development of transmission tower, Telecom tower, substation, and other steel structure and was also at the Forefront in the design of Transmission tower.

over 10 years of experience and innovation in engineering, Designing and building towers has evolved MEGATRO into its current form:

L       Full Turn-Key Provider including site acquisition, engineering services, manufacturing,   field services-DAS, tech services, value Added reseller and monitoring, maintenance and network ownership

L       Specialize in Developing supplying and building wireless and wired networks and in-building Telecommunications systems, as well as energy infrastructure

L       Single source from Design to System Integration

L       Top quality, ISO 9001 registered

A Complete selection of towers including self-support, lattice steel tower, Monopoles and guyed towers, form custom-designed radar towers to broadcast Towers and energy infrastructure. MEGATRO carries a variety of related products Including fall protection, transmission lines, antennas, obstruction lights, and accessories, and other products if client need, MEGATRO also tailored Product as per client condition.

MEGATRO Mainly design all kinds of towers and Posts for:

A.    Telecoms

B.    Power transmission

C.    TV and Radio Broadcast

D.    Roads and City Development

E.    Wind energy solution

F.     Steel structure and Workshop



Our complete selection of towers includes:

A.    Self-supporting

B.    Monopoles

C.    Guyed towers

D.    Custom-designed radar towers

E.    Broadcast towers

F.     Power transmission



MEGATRO also designs and manufactures tower related Products including:

A.    Fall protection

B.    Antenna brackets

C.    Other accessories if needed by clients

Today, with over 10 years of experience and our Commitment to excellence, MEGATRO remains an industry leader in the manufacture and design of steel tubular & angular & monopole structures for all Highway, Municipal, Custom, telecom, lighting and electric Utility Applications. MEGATRO has a complete staff of professional engineering Personnel trained in the PLS Pole program and three different manufacturing Processes for producing steel towers, poles and other supports. We utilize the Latest versions of PLS-CADD, PLS-POLE, TOWER, AutoCAD and other CAD software.

the structure shall be designed according to load Combinations given as per IEC 61936-1 and as illustrated below:
Normal loads
1 Dead weight load
2 Tension load
3 Erection load
4 wind load

Exceptional loads
1 Switching forces
2 short-circuit forces
3 Loss of conductor tension
4 Earthquake forces

Moreover,MEGATROIs fully equipped and qualified to carry out Design Engineering services which includes:

√ Overhead Transmission line steel tower & Telecom steel tower

   Basic Design and Analysis

√ Shop Erection Drawings

√ as-Built Drawings



MEGATROPerforms in-house design activities specializing in electrical overhead Transmission &telecom tower steel works, which include wind and earthquake Loading, static analysis, stress analysis by finite element methods and Fatigue. Our Engineering Department is boasting of highly qualified engineering Who are conversant with international codes and standards. the work is carried Out with extensive use of CAE/CAD via a large of computer network. the computer Hardware & drafting software are liked to the CNC workshop equipment for Downloading of information thereby eliminating error and saving valuable Production time.



Besides, MEGATROis One of the few manufactures who assemble a face of 220KV transmission line LVZT Type suspension tower,. this attention to quality may not be the cheapest Process but it does insure every tower meets our high standards of quality. And It helps to reduce on-site construction cost due to mismatched assemblies. after fabrication all 220KV transmission line LVZT type suspension Tower,s are delivered to the galvanizing facility to Be Hot DIP Galvanized. Towers are processed through the facility by Caustic Cleaning, Pickling, and then Fluxing. these strict procedures insure years of Maintenance free towers. MEGATRO' 220KV transmission line LVZT type Suspension towers systems can accommodate a variety of cross-arm. MEGATRO also offers a wide variety of accessories and mounts.

Other information:
Availability size: Based on the customer's requirements.
Material: Chinese material or as per clients requirement
Steel grades
Tower legs: Chinese steel Q345B, which equivalent to ASTM A572 GR50
Other webs, bracing and not stress plate and angle steel: Chinese Q235B, which equivalent to ASTM A36
Plates: Chinese steel Q345B, which equivalent to ASTM A572 GR50
Bolts: Bolt quality shall be Chinese Class 6.8 and 8.8, as per our Chinese Standard, or ISO 898 standard or ASTM A394 type 0,1,2,3 requirements

the anti-theft bolts shall be Huck bolt Fasteners or approved Equivalent.  The fasteners shall be Manufactured from high tensile steel A242 or equivalent and hot-dip galvanized in accordance with ASTM specification A153 and A394.



Fabrication standard: Chinese Standard or other standard which Client accepted
A) Dimension and tolerance for angle are according to GB/T1591-1994, similar to EN 10056-1/2
B) Hot dip galvanization in accordance with GB/T 13912-2002, which similar to ASTM A 123
C) the welding will be performance in accordance with AWS D1.1 or CWB standard

D) All fastener galvanization conform to ASTM A153 requirements.

Package: both parties discuss before delivery
PortofLoading:QingdaoPort
Lead Time: One month or based on the customer's needs ( for time being our Capacity about 5000 tons one month, and can meet client requirements)
Minimum order: 1 set
