Product Main

Quick Details

Use: Universal
Brand Name: BFT REMOTE CONTROL
Frequency: 433MHZ
Voltage: 12V
Type: FOR THE DOOR
Place of Origin: China (Mainland)
Launch distance: 50-100METER
Transmission speed: 50-60KHZ
Frequency windage: 0.2MHz
key words: BFT
Usage: car windows and doors controller ...

Specifications

Features:


1) 2/4 key RF remote control codes
2) high quality, low cost
3) operation frequency 433.92MHz
4) certification optional: CE (R&TTE ) regulation
5) R
OHS compliant

Rolling code Remote Control

Incdued the follow CHIP IC:

HCS301,HCS300,HCS200


PS: it should work with the receiver with same frequency and rolling code.
BFT MITTO24 433mhz Wireless Remote Control Garage DoorBFT MITTO24 433mhz Wireless Remote Control Garage DoorBFT MITTO24 433mhz Wireless Remote Control Garage Door

Tech Data
Battery model
27A or CR2016
Operation voltage
DC12V/DC6V
Standby current
Less 2uA
Operation frequency
433.92MHz and other can be customized
Frequency offset
+/- 75KHz
Modulation
ASK (Crystal Oscillator )
Transmission current
Less 10mA
Transmission power
10dBm
Buttom quantity
2/4pcs
Encoder(Optional)
Rolling code: HCS301,HCS300,HCS200
Antenna
Printed circuit board
Certification
CE(R&TTE), ROHs Remote Control Codes
Package:
BFT MITTO24 433mhz Wireless Remote Control Garage DoorBFT MITTO24 433mhz Wireless Remote Control Garage DoorBFT MITTO24 433mhz Wireless Remote Control Garage Door
