| Application: | Laser Cutting |
|---|---|
| Certification: | CE |
| Brand Name: | YIZHOULASER |
| Graphic Format Supported: | AI,BMP,DXF,PLT |
| Applicable Material: | Acrylic,Crytal,Glass,Leather,MDF,Paper,plastic,Plexiglax,Plywood,Rubber,Stone,Wood |
| Laser Type: | CO2 |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Model Number: | YZ1630 |
| Place of Origin: | China (Mainland) |
| Control Software: | Trocen |
| Cooling Mode: | Water Cooling |
| CNC or Not: | Yes |
| Cutting Speed: | 400mm/s |
| Cutting Area: | 1600*3000mm |
| Cutting Thickness: | 15mm |
| Condition: | New |
Quick Details
Specifications
APPLICATION
Applicable for fabric,knitting vamps, non-woven, leather, rexine, cotton, felt, silk, lace, polyester, fleece, softshell,jeans,alcantara,neoprene, Corrugated board, cardboard, white board, gray board, sticker, PVC film, foam board, artificial leather, leather, gasket, sponge, Prepreg, fabric, acrylic, honeycomb board, fiberboard, epoxy resin board, organic glass, car mat, fiber, composite material and other soft materials, etc
PARAMETERSModel |
YZ1630 |
Working size |
1600*3000mm |
Price |
FOB QINGDAO |
Max.Cutting thickness |
30mm |
Characteristic |
Computer operation,data transmission fast |
Cutting speed |
0-900mm/s |
Motor and driver |
Digital servo motor and driver |
Laser Power |
150W |
Laser lens |
II-VI |
Air fan |
750W*2 550W*1 |
Material fixing method |
Intelligent divisional vacuum absorption |
Machine resolution |
0.025mm |
Software resolution |
0.025mm |
Transmission interface |
RJ45 Ethernet port |
Air pump |
0.8Mpa non-voice oil compressor |
Memory |
512MB |
Software program |
HP-GL and GP-GL drive language |
HMI |
Resistive touch screen |
Voltage/ Frequency |
AC220V±22V\50±1Hz |
Support format |
BMP, AI, PLT, DST, DXF |
Working Temperature |
0°C-45°C |
Packing size |
2.2*3.5*1.4m |
Weight |
1500KGS |
Package |
Standard wooden case for export |
