Parameter:
Power: AC100-240V, 50-60HZ
Light Source: Yodan 15R 330W or 17R 350W, optional
Power: 650W
DMX512 Channel: 18CHs/22CHs
Working Mode: DMX512, Auto
Display Screen: LED liquid crystal touch screen+button control. Support Chinese and English language. Intelligent overturn function
Color Wheel: one color wheel with 14 colors+white, half-color effect function is available
Pattern Wheel: one fixed pattern wheel with 11 patterns+white and 3 colorful glass patterns(the colorful glass pattern is selectable during existing patterns)
               one rotating glass pattern wheel with 6 high definition stereoscopic effect patterns (outside diameter 24.8mm, pattern diameter 17mm)+atomization
Prism: Two prisms, can be overlayed reciprocally. Prism is optional(3 facet, 8 facet, 16 facet, 24 facet or honeycomb prism). Positive and negative rotation is available
Focus: Linear focus
Zoom: cut-over type zoom in
Product Size: 56*37*26cm
Packing Size: 46*46*58cm
Net Weight: 20KGs
Gross Weight: 22KGs

Feature:
Full and rugged light beams with strong penetrating power;
Excellent prism with sharp effect;
Three phase torsion motor on X axes amd Y axes, provide fast operating speed and sensitive response with no noise.

Fixed Gobo:


Rotated Gobo:
