1. Description:

High resilience spiral cable with or without screen, with oil resistance, wear-resisting,cold resistance, and whether resistance



2. Applications:

Widely used in hostile environments,mechanical engineering,construction industry,construction industry,medical equipment,and used in wet inddor and outdoor enviroment,used in these occasion which need big diameter cable,ect.



3. Construction

Copper conductor	Stranded bare copper/ tinned copper wire, conform to CDE0295 CLASS 5
insuLation	Imported TPE(Lubrizol, Bayer, BASF)
Screen	Screened or non Screen
Sheath	Imported Polyurethan TPE-E(Lubrizol, Bayer, BASF)
Sheath color	Black (other colors and types are available on request)

4. Standard:

DIN 47100, other standard such as: BS, as/NZS, UL upon request



5. Technical data:

Rating voltage: 300/500V,450/750V
Test voltage: 3000V
Insulation resistance: 10Gohmxcm
Working temp:Fixed usage: -35 ℃ to +90℃
Movable usage: -20 ℃ to +90℃
Flame retardant: Conform to IEC60332-1 or 2



6. Certificates:



CE, CB, RoHS, KEMA, SABS, UL, TUV, VDE, SON, SAA, SGS applied
