User-interface

15" TFT LCD display, voice guidance

8 FDKs and / or touch display

EPP keypad be compliant with PCI, vandal resistance

Loudspeakers

Card Reader

Motorized hybrid or dip card reader, EMV certified

Support magnetic/smart card

Card retracted if not removed

Card returned if power failed

Dispenser

Dispensing/deposit speed: 8 notes per second

2-5 cassettes

4 recycling cassettes and 1 reject/deposit box

1 deposit cassette, up to 2300 new notes per cassette

up to 2700/2850 (optional) new notes per recycling cassette

Accepts up to 200 new notes per transaction

Control Unit

Intel core 2 Duo 3.0 CPU, 2G RAM

250G HDD, DVD ROM (optional)

Operating system: Window XP

Printer

Receipt printer: 76mm thermal graphic printer

Journal printer: 80mm dot matrix or thermal printer

Communication

Standard TCP/IP

Optional: dial-up, wireless, X.25, SNA/SDLC

Security

UL291 Standard level 1

Dial combination lock mechanism

Fraudulent device inhibitor (FDI)

EPP shield

Privacy filter (optional)

Customer awareness mirror

Built-in cameras

Integrated media entry/exit indicators

Optional

Barcode reader

Contact-less card reader

Heat booster

Electronic journal

Operating Environment

Voltage: 100V-240V AC, 50/60Hz

Temperature:  0 oC to 40 oC (without heat booster)

                   -35 oC to 50 oC (with heat booster)

Humidity: 20% to 95% Non-condensing

Dimensions and Weight

Dimension: 1612mm X 510mm X 980mm (H x W x D)

Weight: approx. 560kg
