the following example is for you reference.


Main Advantages:



Functionality

 Withdrawal  Deposit  Query  Transfer  Change of PIN

Features

 Top class critical functionality modules

 Reliable performance

• Dustproof and mildew-resistant design
• Stable power supply with EMC compliance User-friendly interface and convenient maintenance

 Ergonomic & absolutely-modularized design

 High security and cost-effective

 Well protected your privacy

Technical details:
User-interface

15" TFT LCD display, voice guidance

8 FDKs and / or touch display

EPP keypad be compliant with PCI, vandal resistance

Loudspeakers

Card Reader

Motorized hybrid or dip card reader, EMV certified

Support magnetic/smart card

Card retracted if not removed

Card returned if power failed

Dispenser

Frictional bundle delivery

Max. 60 notes per bundle

Dispensing speed: 7 notes per second

2-4 cassettes, up to 3000 notes per cassette

Reject & retract bin

Cassette lock (optional)

Control Unit

Intel core 2 Duo 3.0 CPU, 2G RAM

250G HDD, DVD ROM (optional)

Operating system: Window XP

Printer

Receipt printer: 76mm thermal graphic printer

Journal printer: 80mm dot matrix or thermal printer

Communication

Standard TCP/IP

Optional: dial-up, wireless, X.25, SNA/SDLC

Security

UL291 Standard level 1

Dial combination lock mechanism

Fraudulent device inhibitor (FDI)

EPP shield

Privacy filter (optional)

Customer awareness mirror

Built-in cameras

Integrated media entry/exit indicators

Optional

Barcode reader

Fingerprint reader

Contact-less card reader

Heat booster

Electronic journal

Operating Environment

Voltage: 100V-240V AC, 50/60Hz

Temperature:  0 oC to 40 oC (without heat booster)

                  -10 oC to 50 oC (exterior without heat booster)

                  -35 oC to 50 oC (exterior with heat booster)

Humidity: 20% to 95% Non-condensing

Dimensions and Weight

Dimension: 1780mm X 574mm X 1043mm (H x W x D)

Weight: approx. 432kg

Our Factory:

ISO 9001, ISO14001, CMMIL3, PCI, UL, CE,FCC,ROHS, EMV, UL291, PBOC

Our Service:

 Professional Training; Technical Guidelines; Spare PartsOn-site; Support-telephone Support.

---------------------------------------------------------
