| Brand Name: | IPRE |
|---|---|
| Resolution: | zero point zero zreo one um |
| Accuracy: | less than ten percent |
| Measuring Range: | zero point zero zreo five to one hundred sixty um |
| Model Number: | PRSR210 |
| Place of Origin: | China (Mainland) |
| black blue white colour: | four hundred and fourty grams weight |
| usb and bluetooth function: | built in rechargeable Battery |
Quick Details
Specifications
Main Advantages:
1. Customize max 23 parameters;
2. 2 patents obtained (Design patent and Utility model patent )
3. CE certificate
4. Bluetooth function of wireless outputting & printing
5. Mobile app compatible, convenient to be used in the small space
6. Online Software upgrade
7. Extended memory of 8G
8. ARM processor to offer higher speed, low power consumption.
9. 4 kinds of stylus ( probes) optional for the various work pieces
Technical details: 16 Parameters Ra, Rq, Rz, Rv, Rp, Rm, Rt, RS, Rsm,
R3z, R3y, Rz(JIS), Rku, Rsk, Rmax, Rpc Display Ra,Rq:0.005-16μm;Rz,Ry,Rt,Rp,Rv,Rmax,R3z:0.02-160μm;RS,RSm:1mm;Rmr:0-100%(%Rt);Rsk:0-100% Measuring Range ±20m,±40μm,±80μm Resolution (Ra) 0.001μm Filter RC,PC-RC,GAUSS,D-P Cut off 0.25mm,0.8mm,2.5mm Probe Type Inductive Range 160μm Stylus Radius 5μm Measure Force 4mN (0.4gf) Stylus Material Diamond Stylus Angle 90° Number of cut-offs 1 to 5 Max Running Length 17.5mm/0.7inch Min Running Length 1.3mm/0.052inch Accuracy ≤±10% Traverse Speed 0.5mm / s, 1mm/s Output USB and bluetooth Power Built-in rechargeable Battery Dimensions in mm 140×52×48 Weight 440g
Certificates:
CE.CMC.ISO9001. Design patent certificate and so on.
Our Service:
12-month product quality warranty.
